Reno AIM SERIES Premium Panels

Model :

RENO-14BLPL-UNV/347-MWMCCT-HL  1X4 Back-Lit Panel | 20/25/30/40W Selectable Wattage | 3500/4000/5000K Selectable CCT | Up to 133 lm/W | 120-347V

RENO-22BLPL-UNV/347-MWMCCT-HL 2X2 Back-Lit Panel | 20/25/30/40W Selectable Wattage | 3500/4000/5000K Selectable CCT | Up to 133 lm/W | 120-347V

RENO-24BLPL-UNV/347-MWMCCT-HL 2X4 Back-Lit Panel | 30/40/50/60W Selectable Wattage | 3500/4000/5000K Selectable CCT | Up to 133 lm/W | 120-347V

The BP1-Series Hybrid LED Flat Panel ceiling light is a high performance LED panel that uses a unique back-lit design to provide a longer lasting lighting solution that replaces traditional fluorescent lighting or low-end edge-lits found in offices, hospitals, schools and more.

• 0-10V dimmer driver
• 120-347VAC
• Available in 3500K , 4000K & 5000K CCT
• Certification : DLC Premium, Damp Locations, cULus
• 7 year warranty
•  Replacement for 2-4 Lamp  4 Foot T8/T12

KEY FEATURES

• • 83 CRI
  • Lightweight design for quicker installs
  • Backlit technology that offers even light distribution without shadowing
  • Low profile: will fit into any plenum space and directly into existing suspended T-bar ceilings
  • 0-10V dimming
  • Designed to easily fit into existing suspended T-bar ceilings
  • Surface Mount, T-Grid, or Suspended Installation
  • Damp location suitable
